VigilLink VLWP-HD70 HDBaseT 2.0 HDMI Wall Plate Transmitter and Receiver

The VLWP-HD70-TX is a single-gang HDBaseT wall plate transmitter delivering resolutions up to 4K2K at 60Hz (4:4:4) over a single Cat6/6a/7 cable. Reach is 130 feet (40 meters) for UHD and 230 feet (70 meters) for 1080p, which covers most classroom, conference room, and signage runs.

Power over Cable means the plate draws from a compatible HDBaseT receiver, so no local supply is needed behind the wall. Two-way IR and RS-232 give full bidirectional control between the plate and the display end. The matching VLWP-HD70-RX receiver is available separately.
