VigilLink VLIP-SDFRSC-TRX SDVoE 10G Fiber Transceiver with Video Wall and Multiview

The VLIP-SDFRSC-TRX puts an SDVoE encoder and decoder in one 10G fiber unit, transmitting and receiving simultaneously with video wall and multiview processing. It is the fiber counterpart to the copper SDCPSC transceiver.

Video is HDMI 2.0 at 4K@60Hz 4:4:4 with HDCP 2.2 and HDR to 4:2:0 12-bit, distributed losslessly with a local HDMI loop-out. Point-to-point reach is 984 feet (300 meters) over fiber via SFP+, at zero-frame latency with seamless switching. USB HID extension switches between LEX and REX, with independent analog audio, bidirectional IR, and RS-232 alongside.

Output Video Resolutions	Ethernet output: Same as Input Video Resolutions table above
End-to-End Latency	Zero-frame latency
Input Video Port	1 x HDMI, 1 x SFP+ (10GBase-SR)
Input Audio Port	1 x HDMI, 1 x RJ45 (10GBase-T), 1 x 3.5mm jack
Output Video Port	1 x HDMI, 1 x SFP+ (10GBase-SR)
Output Audio Port	1 x 10G BASE-SR (SFP+) port; 1 x LAN (Dante)
Input Audio Format	HDMI/10GBase-T/10GBase-SR: LPCM, 2.0/5.1/7.1 channel, 44.1/48/96/192 kHz, Dolby True HD, DTS-HD Master, Dolby Digital AC-3, DTS version 1; 3.5 mm jack: Unbalanced stereo audio
Output Audio Format	HDMI/10GBase-T/10GBase-SR: LPCM, 2.0/5.1/7.1 channel, 44.1/48/96/192 kHz, Dolby True HD, DTS-HD Master, Dolby Digital AC-3, DTS version 1; 3.5 mm jack: Unbalanced stereo audio
