VigilLink VLIP-SDUDFR-TRX SDVoE 10G Fiber Transceiver with USB and Dante

The VLIP-SDUDFR-TRX switches between encoder and decoder from a button or the API, with an HDMI loop-out in encoder mode. Fiber transport takes it 984 feet (300 meters) point to point, and integrated Dante audio keeps the sound on its own network.

Video is HDMI 2.0b at 4K@60Hz 4:4:4 and 18Gbps with HDR10, Dolby Vision, HLG, and full HD audio to Dolby Atmos and DTS:X, powered over standard 802.3at PoE. Processing covers 9x9 video wall and 25-window multiview, with two-channel Dante audio, USB 2.0 KVM, and bidirectional IR, RS-232, and CEC.

Output Video Resolutions	Ethernet output: Same as Input Video Resolutions table above
End-to-End Latency	Zero-frame latency
Input Video Port	1 x HDMI, 1 x SFP+ (10GBase-SR)
Input Audio Port	1 x HDMI, 1 x SFP+ (10GBase-SR), 1 x 3.5mm jack
Output Video Port	1 x HDMI, 1 x SFP+ (10GBase-SR)
Output Audio Port	1 x 10G BASE-SR (SFP+) port, 1 x LAN (Dante)
Input Audio Format	HDMI/10GBase-T/10GBase-SR: LPCM, 2.0/5.1/7.1 channel, 44.1/48/96/192 kHz, Dolby True HD, DTS-HD Master, Dolby Digital AC-3, DTS version 1; 3.5 mm jack: Unbalanced stereo audio
Output Audio Format	HDMI/10GBase-T/10GBase-SR: LPCM, 2.0/5.1/7.1 channel, 44.1/48/96/192 kHz, Dolby True HD, DTS-HD Master, Dolby Digital AC-3, DTS version 1; 3.5 mm jack: Unbalanced stereo audio
