Crestron HD-RX-4K-510-C-E DMPS Lite 5x1 Multiformat AV Switch and Receiver

The HD-RX-4K-510-C-E is a multiformat AV switch and receiver with enhanced HDMI switching and audio presentation for conference rooms and classrooms. Three DM Lite inputs accept up to three DM Lite 4K60 4:2:0 transmitters, which lets a room take wall-plate and table inputs from separate positions and still land on one box at the display.

A CAT5e or better twisted pair carries each transmitter link: up to 230 ft (70 m) for resolutions to 2K, and a shorter run at 4K. Check Crestron Online Help Answer ID 1001796 for the current list of supported DM Lite transmitters before specifying the far ends.

Dimensions	10.22 in (260 mm) H x 14.18 in (361 mm) with mounting flanges attached W x 1.74 in (45 mm) D
Switcher	5x1 auto-switching or manual, audio-follows-video, Crestron Auto-Locking and QuickSwitch HD technologies
Scaler (HDMI Output)	4K video scaler with motion-adaptive deinterlacing, intelligent frame rate conversion, Deep Color support, content-adaptive noise reduction,...
Scaler Output Resolutions, HDMI	Auto (EDID preferred), 1280x720p@50Hz (720p50), 1280x720p@60Hz (720p60), 1920x1080i@25Hz (1080i25), 1920x1080i@30Hz (1080i30), 1920x1080p@30Hz...
Switcher/Mixer	6x2 audio mixer
Audio, Microphone Inputs	Two balanced 1-channel microphone inputs (MIC 1 and MIC 2)
Audio, Line Inputs	Two balanced/unbalanced 2-channel line inputs (LINE 1 and LINE 2)
Audio, Auxiliary Input	One balanced 1-channel auxiliary input (AUX):
