Crestron HD-PS Series 4K60 4:4:4 HDR Presentation Systems
The HD-PS Series combines 4K60 4:4:4 HDMI switching with audio presentation and DM Essentials extension, so a conference room or classroom gets its whole signal chain from one chassis. HDMI ports carry up to 4K60 at 4:4:4 with HDR10, HDR10+ and Dolby Vision; the DM Essentials port runs 4K60 4:4:4 to 130 ft (40 m) and 1080p60 4:4:4 to 230 ft (70 m) over CATx.
Three sizes are offered. The HD-PS401 has four HDMI inputs with one mirrored HDMI and DM Essentials output; the HD-PS402 adds a second output; the HD-PS622 takes eight inputs to two outputs. All three switch inputs automatically out of the box, so the room works before any programming is written.
| Dimensions | 1.72 in. (44 mm) H x 8.66 in. (361 mm) W x 10.82 in. (275 mm) D |
|---|---|
| Switcher | 4x1 auto-switching or manual, audio-follows-video, Crestron Auto-Locking and QuickSwitch HD technologies |
| Scaler (mirrored HDMI and DM Essentials output) | 4K60 4:4:4 video scaler with motion-adaptive deinterlacing, intelligent frame rate conversion; Deep Color support... |
| Scaler Output Resolutions, HDMI and DM Essentials | Auto-HDMI; Auto-DM Lite; 1280x720p@50Hz (720p50); 1280x720p@60Hz (720p60); 1920x1080p@24Hz (1080p24); 1920x1080p@25Hz (1080p25)... |
| Audio Inputs | (2) mono, balanced analog MIC/LINE inputs; (2) mono, balanced analog LINE inputs... |
| Input Signal Type | HDMI (Dual-Mode DisplayPort interface compatible) |
| Output Signal Type | HDMI |
| Ethernet | 100/1000 Mbps, auto-switching, auto-negotiating, auto-discovery, full/half duplex, DHCP, Web browser setup and control, Crestron control system... |
