Chauvet DJ GigBAR Flex

GigBAR Flex is a complete mobile rig on one bar: a pair of LED derbys for aerial chases, quad-color RGB+UV pars for wash, and a strobe layer, all on four individually adjustable heads. The UV is built into the pars rather than being a separate fixture, so blacklight looks come out of the same bar.

A pass-through mounting hole drops it onto stage and speaker stands directly, and adjustable leg brackets cover floor positions. The wireless footswitch is the part that makes it workable solo, since the effects change hands-free while you are working. Control is 3, 8 or 20 channel DMX over 3-pin XLR. Pars run 6 quad-color LEDs at 3.5 W producing 1,078 lux at 2 m per head at a 13 degree beam, derbys cover 114 degrees, strobe runs to 18 Hz, and 12 units power link at 120 V.

Light Source	(pars): 6 LEDs (quad-color RGB + UV) 3.5 W (1 A), 50,000 hours life expectancy / (strobe): 4 LEDs (white & UV) 5 W (1.5 A), 50,000 hours life expectancy / (derby): 6 LEDs (2 red, 2 green, 2 blue) 5 W (1.6 A), 50,000 hours life expectancy
Illuminance	(pars): 1,078 lux @ 2 m (per head) / (strobe): 86 lux @ 2 m (per zone)
Beam Angle	(pars): 13 degrees / (strobe): 8 degrees
Field Angle	(pars): 24 degrees / (strobe): 18 degrees
Coverage Angle	(derby): 114 degrees
Strobe Rate	0 to 18 Hz
Size	37 x 4 x 15 in ( 949 x 110 x 388 mm)
Weight	11 lb (5 kg)
