Chauvet DJ GigBAR Move ILS
The GigBAR Move ILS puts an entire mobile light show on one 43-inch bar: two moving heads, three quad-color RGB+UV pars, a six-LED derby, a white/UV strobe, and a red-and-green laser, all pre-mounted and pre-wired. The moving heads carry separate color and gobo wheels - seven colors plus white, seven gobos plus open, both continuously scrollable - and pan 540 degrees with 180 degrees of tilt. Totem Mode holds the beams on the dance floor when the bar is stand-mounted at head height.
A built-in D-Fi transceiver makes it the hub of an ILS rig: it can drive other ILS fixtures wirelessly or follow them, so a DJ adds uplights or effects without running data cable across a venue. Control runs at 3, 27, or 46 DMX channels over 3-pin XLR, and both an RF remote and a 433 MHz wireless footswitch are in the box. The whole system draws 81W at 120V, links seven units to a circuit, and ships with a tripod that adjusts from 4.8 to 8.3 feet.
| Light Source (moving head) | 2x 1 LED (cool white) 10W, 50,000-hour life |
|---|---|
| Light Source (pars) | 3 LEDs (quad-color RGB+UV) 3.5W |
| Light Source (derby / strobe) | 6 LEDs (2R/2G/2B) 1W; 4 LEDs (white & UV) 5W |
| Laser | 650nm/100mW red + 532nm/30mW green diodes |
| Pan / Tilt | 540° / 180° |
| DMX Channels | 3, 27 or 46; 3-pin XLR |
| Power | 81W, 1.1A @ 120V; power-links 7 units @ 120V |
| Size / Weight | 43 x 5.7 x 17.7 in (1100 x 144 x 449 mm); 23.4 lb (10.7 kg) |
