Yamaha MGX Series Digital Mixer

The Yamaha MGX series is a compact digital mixer line built for streamers, podcasters, and small production teams, controlled from a 4.3-inch touchscreen and rackmountable with the optional RK-MGX ears. The MGX12 runs 4 combo mic/line preamps into 18-channel mixing with dual USB ports for simultaneous 18-in/18-out recording plus a separate 2-in/2-out streaming feed, while the MGX16 doubles the preamp and output count to 8 for larger setups, both recording up to 22 tracks at 96 kHz over USB or 16 tracks to a microSD card.

The V models add a built-in HDMI video interface, an HDMI IN for a camera or game console and an HDMI THRU for a monitor, that captures up to 4K60 and sends it to a computer over USB alongside the audio, so a single MGX handles a full audio/video stream without a separate capture card. Every size ships in black or white.
