MuxLab 500485 HDMI 2.0 Fiber Extender Kit, Single Mode
The 500485 puts a 4K/60 HDMI source on single-mode fiber and carries it up to 10km (6.25 miles), well past what any copper HDBaseT run can reach, with HDCP 2.2 compliance so protected content still plays at the far end.
A USB 1.1 pass-through lets a keyboard and mouse reach back to the source for touch or presentation control, and bidirectional IR keeps a remote working at the display. Wall-mount brackets are included for both ends of the run.
| Signal Format | HDMI 4K @ 60fps (4:4:4, 8-bit) |
|---|---|
| HDCP | HDCP 2.2 |
| HDR | 4K @ 60fps (4:2:0, 10-bit) |
| Max. Distance | 10 km (6.25 miles) over single mode fiber |
| Control | Bi-directional IR pass-through, 20kHz - 60kHz |
| Compatibility | USB 1.1 keyboard/mouse pass-through |
| Weight | 1.600 kg |
| Mounting | Wall-mount bracket kit included |
