MuxLab 500702 LongReach 3G-SDI Extender Kit

The 500702 kit extends 3G-SDI over a single Cat5e/6 cable, carrying up to 2.97/3.0 Gbps of uncompressed, unencrypted digital video with up to 32 channels of embedded audio and time code. This long-reach model holds all resolutions to 500ft (150m).

Supported standards are SDI SMPTE 259M-C, HD-SDI SMPTE 292M, and HD-SDI SMPTE 424M/425M. It is the version to specify when a standard 100m SDI-over-UTP link falls just short of the camera position.

Standard	SDI single link: SD, HD & 3G
Maximum distance	applies for all format and speed between boxes. On the SDI side, the use of an equalizer at input and a clock regenerator at output allow to reach the maximum distance on coax
Power Consumption	Transmitter: 4 Watts Receiver: 8 Watts
Power	Supply (Included) Two 100-240V/5-12VDC 15W power supplies with interchangeable blades for NA, Europe and UK
Dimensions	4.50" x 3.00" x 1.25" (11.4 x 7.6 x 3.2 cm)
Weight	2.5 lb. (1.1 kg)
Enclosure	6061 Aluminum alloy
Compliance	Regulatory: FCC, CE, RoHS Flammability: 94V0
