MuxLab 500700 3G-SDI Extender Kit

The 500700 kit transmits 3G-SDI up to 330ft (100m) over a single Cat5e/6 cable, point to point, carrying up to 2.97/3.0 Gbps of uncompressed, unencrypted digital video. Up to 32 channels of embedded audio and embedded time code travel with it.

Supported standards are SDI SMPTE 259M-C (270Mbps), HD-SDI SMPTE 292M (1.485 and 1.485/1.001 Gbps), and HD-SDI SMPTE 424M/425M (2.97/3.0 Gbps). Using structured cable instead of coax means an SDI camera position can move to wherever a data outlet already is.

Standard	SDI single link: SD, HD & 3G
Maximum distance	applies for all format and speed between boxes. On the SDI side, the use of an equalizer at input and a clock regenerator at output allow to reach the maximum distance on coax
Power Consumption	Transmitter: 4 Watts Receiver: 8 Watts
Power	Supply (Included) Two 100-240V/5-12VDC 15W power supplies with interchangeable blades for NA, Europe and UK
Dimensions	4.50" x 3.00" x 1.25" (11.4 x 7.6 x 3.2 cm)
Weight	2.5 lb. (1.1 kg)
Enclosure	6061 Aluminum alloy
Compliance	Regulatory: FCC, CE, RoHS Flammability: 94V0
