BZBGear BG-IPGEAR-XTREME AV over IP Transceiver

The IPGEAR-XTREME moves BZBGear's AV-over-IP platform to HDMI 2.1 while keeping it on a single gigabit network. Each unit is configurable as an encoder or a decoder, and the system does seamless matrix switching, multiview and KVM without a separate matrix frame.

The chassis is small - 132 mm across - and wall-mountable, with HDMI in, USB and USB-C on the front of the signal path, an RJ-45 for the network, a 3.5 mm audio port and an RS-232 terminal block. IR passes in both directions. It interoperates with the XTREME wall plates and the XTREME PRO on the same network.

HDMI compliance	HDMI 2.1
HDCP compliance	HDCP 2.3
Video support	up to 4K@120 4:4:4
Video bandwidth	up to FRL 5 (40G)
Transmission distance	4K@120 4:4:4 170m (560ft) [CAT.5E/6/6a/7]
Audio support	Surround sound [up to 7.1ch]
Inputs	1x HDMI, 1x 3.5mm, 1x USB, 1x USB-C
Outputs	1x 3.5mm, 1x RJ-45
Power supply	12V DC, 1A
Dimensions (L x W x H)	5.2 x 3 x 0.79in [132 x 75 x 20mm]
Weight	1.1 lbs [0.5kg]
