BZBGear BG-VOP-MT AV over IP Transceiver

The VOP-MT is a single box that is set as either the sending or the receiving end of a 4K HDMI-over-IP system, so a project is stocked with one part number instead of two. Input accepts up to 4K60 4:4:4 and output runs to 4K30 RGB, with a maximum of two frames of latency over a 100 metre copper run.

USB ports carry keyboard and mouse back to the source for KVM, and IR and RS-232 pass in both directions. It takes power over Ethernet or from the 5 V supply, mounts on a wall, and is managed by the BG-VOP-CB controller.

Role	Transceiver
Input video support	Up to 4K2K@60 (4:4:4 8bits)
Output video support	Up to 4K2K@30 (RGB)
Latency	2 frames (33 ms) maximum
Transmission distance	Ultra HD (4K2K@60) - 100m (328ft) [CAT.X]
Audio support	Surround sound (up to 7.1ch) or stereo digital audio
Connectors	2x HDMI + 4x 3.5mm + 3x USB + 1x RJ45 + 1x DIN9
IR pass-through	Full-duplex bi-directional
Power supply	5V 2A DC / 48V POE
Dimensions (L x W x H)	7" x 5.5" x 3.2" [180 x 142 x 28mm]
Housing	Metal enclosure
