Analog Way HDMI 2.0 Fiber Extender Power Tray

The OPT power trays give a rack of EXT-HDMI20-OPT transmitters and receivers a single fixed home, a single mains feed and a proper front-panel fiber termination. Each is a 1RU steel enclosure with a C14 inlet, 85 - 264 VAC input, and a 5 V USB type A output per slot rated at 500 mA, protected against overload and short circuit. Cooling is passive, so the tray adds no fan noise to a control position, and the extenders' HDMI tails come out directly at the back where the sources and displays are.

Three versions differ only in slot count and how the fiber lands. The NTD holds eight extenders behind four Neutrik opticalCON Duo connectors, two fibers each. The NTQ holds sixteen behind four Neutrik opticalCON Quad connectors, four fibers each, for touring runs on ruggedised trunk. The SC also holds sixteen but terminates in eight SC Duplex connectors for installed plant that is already patched to SC. All three share the same chassis, the same 4.13 kg weight and the same inner optical looms, numbered for identification.
