Name: Magewell Modator 2U Chassis (B5220)
Brand: Magewell
SKU: B5220
Price: 2539.00 USD
Availability: InStock

Modator 2U delivers the robust capabilities of Magewell's IP encoders and decoders in a scalable, high-density form factor. Connections: 10* Modator slots supporting hot swap of Magewell modules; 1* RJ45 1000Mbps Ethernet port for configuration; 1* USB Type-C port for configuration.

Setup and monitoring: Touchscreen Power on/off the device; Display the device information. It measures 482mm (L) x 275mm (W) x 88 mm (H). Power: Hot-swappable dual power supply modules for safety and redundancy; AC: 100-240V, 7-3.5A, 60/50Hz.

Part Number	B5220
Interfaces	10* Modator slots supporting hot swap of Magewell modules; 1* RJ45 1000Mbps Ethernet port for configuration; 1* USB Type-C port for configuration
Control	Touchscreen Power on/off the device; Display the device information; Display information about the connection state of each slot and information of inserted modules
Form Factor	Form factor: 482mm (L) x 275mm (W) x 88 mm (H); Weight: approx. 5.6kg (with 10 blank panels)
Power	Hot-swappable dual power supply modules for safety and redundancy; AC: 100-240V, 7-3.5A, 60/50Hz; Maximum power consumption of the chassis: 200W
Operating Range	Operating temperature: 0 to 50 deg C; Storage temperature: -20 to 70 deg C; Relative humidity: 5% to 90% non-condensing
