JBL PRX935 Powered three-way 15-inch loudspeaker
The PRX935 is the three-way model: a 916G 15-inch woofer, a dedicated 196H 6-inch midrange driver and a 2408H-2 compression driver, crossed at 542 Hz and 2,100 Hz. Giving the midrange its own transducer is what separates this cabinet from the two-way models - vocals sit forward and stay legible at high level, which is why it turns up in worship rooms and corporate rigs.
The DSP suite is reached from an onboard colour LCD or from the JBL Pro Connect app over Bluetooth: 12-band parametric EQ, dbx DriveRack Automatic Feedback Suppression, a soft system limiter with a Soundcraft Overeasy option, and 180 ms of speaker delay in 100-microsecond steps. One app session controls up to ten cabinets and lines the PRX900 up with EON700, PRX ONE and EON ONE MK2 systems. Maximum output is 136.1 dB with response to 40 Hz at -10 dB, and the cabinet takes eight M10 points or a 36 mm pole.
| Type | Powered three-way 15-inch loudspeaker |
|---|---|
| Amplifier power | 2000 W peak, Class D |
| Maximum SPL | 136.1 dB |
| Frequency range (-10 dB) | 40 Hz - 20 kHz (4 pi) |
| Frequency range (-3 dB) | 46 Hz - 18 kHz (4 pi) |
| Coverage pattern | 90 x 50 degrees |
| Transducers | 916G 15-inch woofer; 196H 6-inch midrange; JBL 2408H-2 1.5-inch compression driver |
| Crossover frequencies | 542 Hz and 2100 Hz |
| Inputs / outputs | 2 combo inputs, 3.5 mm stereo jack; 2 XLR thru-outs, 1 mix out |
| Mounting | 8 x M10 suspension points, single 36 mm pole mount |
| Dimensions (H x W x D) | 938.5 x 446 x 434 mm (36.9 x 17.6 x 17.1 in) |
| Net weight | 36.6 kg (80.7 lb) |
