BZBGear BG-IPGEAR-XTREME-W-T Wall Plate Encoder
The XTREME-W-T is the transmitter half of BZBGear's wall plate AV-over-IP pair. It replaces a plate at the source position - a lectern, a huddle table, a wall input in a waiting area - and puts HDMI, DisplayPort or USB-C video onto the gigabit network without a box on show or a shelf to mount it on.
It is an encoder only. Video travels to any XTREME receiver on the same network in point-to-point, point-to-multipoint or multicast configurations, and it interoperates with the standard XTREME transceivers and the XTREME PRO, so a plate at one end can feed a rack-mounted decoder at the other.
| Role | Transmitter / encoder |
|---|---|
| HDMI compliance | HDMI 2.1 |
| Video support | Up to 4K@120Hz 4:4:4 |
| Transmission distance | Up to 170 m (560 ft) over Cat.5e/6/6a/7 |
| Video inputs supported | HDMI, DisplayPort and USB-C (Alt Mode DP 1.4) |
| USB | USB 3.1 for UVC devices |
| IR | Bi-directional IR pass-through |
| Network | 1 Gigabit Ethernet switch with IGMP Snooping; 802.1Q VLAN supported |
| Distribution modes | Point-to-point, point-to-multipoint and multicast |
| Form factor | Wall plate |
| System compatibility | Interoperable with BG-IPGEAR-XTREME and BG-IPGEAR-XTREME-PRO on the same network |
