AtlasIED PM4FA-B 4" 2-way Pendent Mount Speaker with 16-Watt 70.7V Transformer - Black
The AtlasIED PM4FA-B is a 4" 2-way pendent mount speaker with 16-watt 70.7V transformer - black. The AtlasIED PM4FA features the familiar response and dispersion of AtlasIED's model FA134 high performance 4" Strategy Series driver. This speaker is the same FA Series device used in AtlasIED's successful model FAP42T ceiling speaker package. It runs a coaxial driver over 70Hz - 20kHz.
Mounted down-firing in an attractive enclosure, the PM4FA provides natural impressive full range frequency response for both music and paging applications. Attaching a PM4FA to most over head surfaces is a breeze. AtlasIED lists 4" FA134 driver provides 130° degree (65 degree off-axis) coverage in the 2kHz octave band; 70.7V taps @ 1, 2, 4, 8 and 16 watts plus 8-ohm direct input via concealed terminal block; 3 meters of 2mm cable & mounting hardware included; compatible with standard 3/4" ceiling fan hardware. It measures 9 1/4" in diameter. It carries a manufacturer warranty of 60 months from date of purchase.
| Part Number | PM4FA-B |
|---|---|
| Speaker Type | Coaxial |
| Sensitivity | 88dB Average |
| Frequency Response | 70Hz - 20kHz |
| Impedance | 1, 2, 4, 8, 16 Watts and 8Ω |
| Dispersion | 130° |
| 8Ω RMS Power | 25 Watts |
| Diameter | 9 1/4" (23.495 cm) |
| Warranty Period | 60 months from date of purchase |
