AtlasIED PM8CX-B 8" 2-way High Output Pendent Speaker with 60-Watt 70V Transformer - Black

The AtlasIED PM8CX-B is an 8" 2-way high output pendent speaker with 60-watt 70V transformer - black. Model PM8CX-B includes the AtlasIED 8CXT60 compression driver coaxial speaker which provides excellent efficiency exceeding 92dB 1W/1m. The 8CXT60 also offers a desirable tighter 90 degree conical coverage pattern in the 2kHz octave band for great coverage performance in ultra high mounting locations up to 30'. It runs a coaxial driver over 55Hz - 15kHz.

AtlasIED lists 70.7V taps @ 7.5, 15, 30 & 60 watts plus 8-ohmDirect input via concealed terminal block; 8" 8CXT60 driver provides 90 degree (45 degree off-axis) coverage in the 2kHz octave band; 3 meters of 2mm cable & mounting hardware included; compatible with standard 3/4" ceiling fan hardware. It carries a manufacturer warranty of 60 months from date of purchase.

Part NumberPM8CX-B
Speaker TypeCoaxial
Sensitivity92dB Average
Frequency Response55Hz - 15kHz
Impedance7.5, 15, 30, 60W & 8Ω
8Ω RMS Power150 Watts
Dispersion90°
Warranty Period60 months from date of purchase
