AtlasIED ECM-20 20A AC Power Conditioner and Spike Suppressor

The AtlasIED ECM-20 is a 20A AC power conditioner and spike suppressor. The Atlas Power ECM-20 is a 20A Power Conditioner and AC Spike Suppressor that is designed to be used as a standalone unit or in conjunction with an ECS unit up to 1000ft away. The ECM-20 features AC Spike and Surge Suppression, AC Mains Voltage monitoring, EVS circuitry, and Remote Activation.

The ECM-20 is designed to be conveniently housed in the ECM-RACEWY6 for the addition of multiple outlets directly connected to the AC mains from the electrical panel. AtlasIED lists 2 outlets, 20A; manual/auto on/off switch; incoming AC present LED; active LED. It measures 3.0" (76.2mm) high, 8.5" (215.9mm) wide, and 3.5" (88.9mm) deep. It is certified to MET (UL 1449) and carries a manufacturer warranty of 12 months from date of purchase.

Part Number	ECM-20
Current Rating	20 Amps
Power Requirement	120V 60Hz
Certified to Safety Listing	MET (UL 1449)
Operating Voltage	102-132VAC
Minimum Spike Clamping Voltage	460 VRMS @ 3000A
Maximum Spike Clamping Voltage	6,000V
Power Consumption	.5 Watts
Height	3.0" (76.2mm)
Width	8.5" (215.9mm)
Depth	3.5" (88.9mm)
Weight	1.25 lbs. (.68 kg)
Warranty Period	12 months from date of purchase
