AtlasIED ECS-204 20A Power Conditioner & Sequencer

The AtlasIED ECS-204 is a 20A power conditioner & sequencer. The AtlasIED ECS-204 is a 20 amp AC Power Sequencer and Conditioner. The ECS-204 has been designed to meet most installation requirements for AC power distribution and equipment power protection.

The 20A compact 1 RU unit features four internal sequential timing sections, three on the unit and one to trigger an external device. All can be activated via the unit locally or remotely. AtlasIED lists 9 total 20A outlets; 6 rear panel outlets sequenced in 3 stages; 1 rear panel unswitched outlet; 2 front panel unswitched outlets. It measures 1.75" (44.45mm) high, 19" (482.6mm) wide, and 8.5" (215.9mm) deep. It carries a manufacturer warranty of 12 months from date of purchase.

Part Number	ECS-204
Load Rating	20A
Minimum Spike Clamping Voltage	460 VRMS @ 3000A
Maximum Spike Clamping Voltage	6000V
Power Consumption	12 Watts
Operating Voltage	102 - 132VAC
Energy Rating	2000 Joules
Spike Clamping Voltage @ 100A	1250Vp for 20µs
Maximum Surge Current	6500A
Temperature Range	5° to 35°C
Humidity Range	5% to 95% R.H.
Height	1.75" (44.45mm)
Width	19" (482.6mm)
Depth	8.5" (215.9mm)
Weight	10 lbs. (4.53kg)
Warranty Period	12 months from date of purchase
