MuxLab 500450 HDMI Extender Kit Plus, HDBT, UHD-4K
The 500450 kit extends HDMI up to 330ft (100m) at all resolutions up to 4K over a single Cat5e/6 cable, point to point. It supports HDMI 1.3a and 3D, and ships as a transmitter and receiver pair.
An IR emitter (500998) and IR sensor (500999) are included, so the source can be controlled from the display end with the original remote. The -LR version is the long-reach variant of the same kit. Both are ordinary two-box installs with no configuration to do.
| Standard | HDMI 1.3a |
|---|---|
| Signal Format | HDMI 1.3a protocol |
| Bandwidth | 148.5MHz |
| Cable | One (1) Category 5e or better twisted pair cables required |
| Power Supply | Two (2) 110-240V/5VDC power supplies with interchangeable blades |
| Power Consumption | Transmitter: 4 Watt Receiver: 6 Watt |
| Dimensions | 4.50" x 3.00" x 1.25" (11.4 x 7.6 x 3.2 cm) |
| Weight | 2.6 lb (1.2 kg) |
