MuxLab 500446 4x2 HDMI 2.0 Quad-View Processor

The 500446 accepts four HDMI 2.0 sources at up to 4K/60 4:4:4 and composes them into a single multi-view image sent to both of its outputs at 4K/60. Five default layout presets are provided, plus eight custom presets where windows are resized and positioned as required, including picture-in-picture.

It is HDCP 2.2 compliant and can send the same multi-view arrangement to two displays simultaneously, which is what a control room or a production gallery usually needs. Sources can also be routed straight through when a single full-screen feed is wanted.

Standard	HDMI 2.0 (4K/60 4:4:4 8 bit) HDMI Devices DVD/Blu-Ray/Media Players, Cameras, PCs/Laptops, projectors/monitors/TVs
Frequency	Up to 594 MHz
Audio	Extraction From 2CH Digital PCM, to 2CH Analog Audio
Power Supply	12VDC,5A
Power Consumption	22W (max)
Temperature	Operating: 0 deg to 40 deg C Storage: -20 deg to 60 deg C
Humidity	up to 90% non-condensing
Compliance	Regulatory: FCC, CE, RoHS
