Electro-Voice EKX-12P 12-Inch Two-Way Powered Loudspeaker

The EKX-12P is the powered version of the 12-inch EKX cabinet. A 1500 W Class D amplifier drives the EVS-12M woofer and DH-1M titanium compression driver, and QuickSmartDSP handles the crossover, limiting and voicing behind a single knob and an LCD on the back panel. Setup is a matter of picking a preset rather than carrying a rack.

Inputs are two XLR/TRS combo jacks plus a stereo RCA pair, with an XLR link output for the next box down the line. Frequency response reaches 60 Hz at -3 dB, so it holds up on speech and light music without a sub. The plywood enclosure carries eight M10 fly points and an aluminium pole socket, same as the passive model.

Type	12-inch two-way powered loudspeaker
Amplifier	1500 W Class D
Frequency response (-3 dB)	60 Hz - 18 kHz
Coverage (H x V)	90 x 60 degrees
Maximum SPL	132 dB
Transducers	EVS-12M 300 mm (12 in) woofer; DH-1M 1-inch titanium compression driver
Crossover frequency	1.7 kHz
Processing	QuickSmartDSP, single-knob interface with LCD menu
Inputs / outputs	(2) XLR/TRS combo, (1) stereo RCA, (1) XLR link output
Enclosure	15 mm plywood with EVCoat
Dimensions (H x W x D)	607 x 375 x 356 mm (24 x 15 x 14 in)
Net weight	18.8 kg (41.4 lb)
Rigging	(8) M10 threaded mounting points
