Chauvet DJ Swarm 5 FX ILS
The Swarm 5 FX ILS packs three classic party effects into one fixture: a rotating RGBAW derby for scattered color across the room, a red (650nm/100mW) and green (520nm/30mW) laser for beam and gobo-style effects, and a white strobe ring for hits and blackouts. Running all three from a single mounting point saves rig space and DMX addresses compared to buying separate derby, laser, and strobe units.
ILS ecosystem compatibility lets it link wirelessly with other ILS fixtures, and D-Fi USB support adds untethered DMX control for a mobile DJ or small production. DMX operation uses 9 channels for full independent control of all three effects, the fixture draws about 62W, and at 9.8 lbs it mounts on a stand, truss, or ceiling bracket for dance floor coverage.
| Derby LEDs | 5 (RGBAW), 3W each |
|---|---|
| Strobe LEDs | 8 white, 1W each |
| Laser | Red 650nm/100mW; Green 520nm/30mW |
| DMX Channels | 9 |
| Power Draw | 62W (0.5A @ 120V / 0.3A @ 230V) |
| Coverage Angle | Laser 100°; Derby 65° |
| Dimensions | 9.75 x 11.7 x 12.2 in (248 x 298 x 310 mm) |
| Weight | 9.8 lbs (4.5 kg) |
