BZBGear BG-CHA USB 3.0 HDMI Capture Card with Scaler
The BG-CHA puts a camera, console or second computer into OBS, AMCap or a conferencing client as a standard USB video device. It handles resolutions up to 1080p60 on a USB 3.0 or 3.1 port and includes a scaler, so an odd source resolution can be brought to something the software will accept.
A 3.5 mm stereo input lets an external microphone or a mixer feed be embedded into the captured stream instead of using the HDMI audio. The housing is aluminium and the card runs on USB power alone at about 4W. It is HDCP compliant, so protected content will not record. The unit is TAA compliant.
| UAC Video Output Resolution | UHD Video Standards: 1080p at 60/50/30/25/24 Hz HD Video Standards: 720p at 60/50/30/25/24 Hz 1080p at 23.98/24/25/29.97/30 Hz VESA Standards: 1280x1024p at 60/50/30/25/24 Hz 1280x720p at 60/50/30/25/24 Hz 1024x768p at 60/50/30/25/24 Hz 600p at 60/50/30/25/24 Hz 480p at 60/50/30/25/24 Hz |
|---|---|
| Recording Video Format | YUY2 (USB3.1 Gen 1), MJPG (USB2.0/3.1 Gen 1) |
| UAC Audio Output Format | Stereo / 16-bit / 48000Hz |
| Audio Input | HDMI Embedded Audio 3.5mm Analog Stereo Audio |
| Power Supply | 5V DC, 1A |
| Power Consumption | 4 watts (Max) |
| Max. Data Rate | 350 Mbps |
| Operating System Compatibility | Windows 7, 8, 10, Mac OS X 10.9 or above, Linux |
