Tascam US-16x08 USB Audio/MIDI Interface
The US-16x08 gives a desktop rig 8 XLR mic inputs and 8 TRS line inputs, two of them switchable to instrument level, running through Tascam's Ultra-HDDA discrete preamp design rated at -125 dBu equivalent input noise with 56 dB of gain, enough clean gain for dynamic or ribbon mics that need it. Sixteen inputs and 8 balanced TRS outputs over USB 2.0 record a full band at once at up to 96kHz/24-bit.
A 5-pin MIDI in/out adds a hardware controller or synth to the same interface without a separate MIDI box, and Class Compliant drivers make it work with an iPad or iPhone for tracking on the go. At 6.11 lb and 17.5 inches wide, it sits on a desk or in a half-rack shelf rather than needing a full studio rack.
| Configuration | 16-in / 8-out USB audio/MIDI interface |
|---|---|
| Inputs | 8 XLR mic, 8 TRS line (2 switchable to instrument) |
| Preamps | Ultra-HDDA, -125 dBu EIN, 56 dB gain |
| Sample Rate | Up to 96 kHz/24-bit |
| MIDI | 5-pin DIN in/out |
| Connectivity | USB 2.0 High Speed, iOS Class Compliant |
| Dimensions | 17.5 in W x 2.32 in H x 8.62 in D |
| Weight | 6.11 lb (2.8 kg) |
