Kramer WM-6P 6.5" Two-Way Wall Mounted Passive Speaker
The WM-6P is the passive version of Kramer's 6.5-inch wall speaker: no amplifier or network connection inside, just a 165mm polypropylene woofer and a ferrofluid-cooled soft dome tweeter wired to a 4-pin Euroblock terminal. A field-selectable tap switches it between low-impedance 8-ohm operation off a standard amp and 70V or 100V constant-voltage operation for a distributed paging or background-music line.
It shares the WM line's EasyMount bracket for vertical, horizontal, or corner mounting, plus a standard 75mm VESA thread for other mounts. Rated to 30W continuous (45W peak) at 8 ohms, it is built for meeting rooms, retail floors, and mixed-use spaces where the same cabinet needs to work on either a home-run amp or a tapped 70V line.
| LF Driver | 165mm (6.5") polypropylene cone, rubber surround |
|---|---|
| HF Driver | 25mm (1") soft dome, ferrofluid-cooled |
| Frequency Response (+/-3dB) | 84 Hz - 20 kHz |
| Power @ 8 ohm | 30W continuous / 45W peak |
| Power @ 70V / 100V Taps | 30W / 15W / 7.5W (70V adds 3.8W tap) |
| Sensitivity | 90dB SPL (1W @ 1m free field) |
| Max SPL | 104dB continuous / 106dB peak |
| Connector | 4-pin pluggable Euroblock, 28-12AWG |
| Dimensions (with bracket) | 200 x 246 x 310 mm |
| Weight (with bracket) | 3.7 kg (8.2 lbs) |
