FSR HD-HWP-Tx HDBaseT HDMI Wall Plate Transmitter

The HD-HWP-Tx is the source end of an HDBaseT link with no box to hide. A 2-gang Decora plate takes the HDMI lead from a lectern or a wall position and puts video, audio, bidirectional IR and RS-232, Ethernet and power onto one shielded CAT-6A run.

It reaches 100 m at up to 4K 60Hz and draws its power back down the cable from a compatible FSR HDBaseT receiver, so the wall position needs no outlet behind the plate. That is usually the difference between a clean wall and a surface-mounted brick.
