FSR HD-H704K-WP HDBaseT 70 m Wall Plate Extender Set
This is the extender bought as a pair so nothing has to be matched later: a single-gang wall plate at the source, a compact brick behind the display, one CATx run between them. HDMI 2.0 with HDCP 2.2 and HDR, 4K 60Hz 4:4:4 out to 40 m, 1080p out to 70 m.
Control travels with the picture, with bidirectional RS-232 plus IR and CEC pass-through, so the display can be driven from the source end. S/PDIF de-embeds audio at the receiver for a local amplifier, and downscaling to 1080p keeps an older display in the system.
| Product Type | HDBaseT extender set, wall plate to brick |
|---|---|
| Contents | Single-gang wall plate transmitter and compact brick receiver |
| Standards | HDMI 2.0, HDCP 2.2, HDR |
| Distance | 4K at 60Hz 4:4:4 to 40 m; 1080p at 60Hz to 70 m |
| Cable | One CATx run |
| Control | Bidirectional RS-232, IR pass-through, CEC pass-through |
| Audio | S/PDIF audio de-embedding |
| Scaling | Downscales to 1080p for lower resolution displays |
