Kiloview N40 Plus 4K HDMI Bidirectional NDI Converter

The N40 Plus puts a 4K60 HDMI signal onto the network as full-bandwidth NDI, or takes NDI off the network and puts it back on HDMI. Full NDI High Bandwidth rather than HX is the point of this model: it is the version to use when the receiving end is a production switcher and the picture has to survive being keyed and cut, not just watched.

It encodes in SpeedHQ at SHQ0 or SHQ2, has an HDMI output that loops the input through when encoding and becomes the decoded output when decoding, and carries a 3.5mm line in and out for audio.

Video Port	1 x 4Kp60 HDMI, input 1 x 4Kp60 HDMI, output for decoding/loop-out for encoding
Video Encoding and Decoding	SpeedHQ (NDI): SHQ0, SHQ2
Streaming Protocols	NDI HB
Interlaced Video Support	1080i60 interlaced input and 1080i60 interlaced output encoding
Color Space	* Encoding NDI HB: YCbCr 4:2:0, 4:2:2 * Decoding NDI HB: YCbCr 4:2:0, 4:2:2
Color Depth	8-bit
Audio Port	1 x 3.5mm Line in/Line out
Audio Encoding and Decoding	NDI Audio and more audio formats and channels available through custom development
