JVC KM-IP4000S

The KM-IP4000S is the sports-production version of JVC's ProHD live streaming studio. It carries the same four-channel core as the KM-IP4000, four HD-SDI inputs plus four IP and four NDI inputs and an HDMI input, and adds slow-motion playback for the instant reviews and highlight cuts that sports coverage lives on. IP inputs accept NDI, RTSP, RTMP, UDP unicast and multicast, HLS, and SRT.

Like the base studio it runs 4:4:4:4 ARGB processing, a full audio mixer, and simultaneous program-stream recording, so a game can be switched, replayed, streamed, and archived from one compact system. Program output is on HD-SDI and HDMI, with a separate HDMI/DisplayPort multiview or program feed, and streaming reaches up to 1080 50/60p at 10 Mbps. It tracks and controls JVC PTZ cameras and Connected Cam camcorders and pushes to platforms like Facebook Live.
