DVDO Splitter-14-CAT 4K 1x4 HDMI Splitter with Category Outputs

The Splitter-14-CAT is DVDO's 4K 1x4 HDMI Splitter with Category Outputs, from the hdmi splitters line. Includes 1x4 splitter and 4 CAT receivers.

HDMI 2.0b, HDCP 2.2 and HDCP 1.x compliant. 18Gbps video bandwidth. Supports video resolutions up to 4K2K@50/60Hz 4:4:4. HDR, HDR10+, HLG, Dolby Vision. Up to 7.1CH HD audio pass-through.

Feature	Includes 1x4 splitter and 4 CAT receivers
HDCP	HDMI 2.0b, HDCP 2.2 and HDCP 1.x compliant
Performance	18Gbps video bandwidth
Video	Supports video resolutions up to 4K2K@50/60Hz 4:4:4
Audio	HDR, HDR10+, HLG, Dolby Vision
Also	Up to 7.1CH HD audio pass-through
Reach	Extend the signal transmission distance up to 115ft/35m at the resolution of 4K2K@60Hz, 164ft/50m at 4K2K@30Hz, 197ft/60m at 1080P@60Hz via a single CAT6/6a/7 cable
Connectivity	1 HDMI input, 1 HDMI loop output and 4 CAT outputs
Control	20-60Hz IR control source equipment from Rx side
Signal Handling	Advanced EDID management
Product Category	HDMI Splitters
Part Number	DVDO-Splitter-14-CAT
