RCF TT 20-CXA Active Two-Way Stage Monitor

The TT 20-CXA is a low-profile stage wedge with a symmetrical two-woofer layout, which is what keeps the 90 by 70 degree pattern consistent whichever side of the box a performer stands on. Two 8-inch neodymium woofers and a 1.5-inch compression driver on a 3-inch voice coil share a 2000 W peak, 1000 W RMS amplifier for 131 dB at one meter from 60 Hz to 20 kHz.

FiRPHASE processing gives the transient response monitors usually give up, and the flat phase through the 900 Hz crossover is audible as clarity in a loud wedge mix. A pole socket lets the same cabinet work as a compact front-of-house top when the rig changes. RDNet over Ethercon handles EQ and monitoring, and the Baltic birch cabinet weighs 30.86 lbs.
