Panasonic PT-VMW51U7 Laser Projector
The Panasonic PT-VMW51U7 is the WXGA model in the portable VM laser line: 5,200 lumens from a 3-chip LCD engine at a native 1,280 x 800, with HDMI inputs that accept 4K source signals and scale them to the panel. Unlike the fixed-lens short-throw models, this one carries a 1.6x manual zoom and lens shift (horizontal +/-20%, vertical +44%), so it can be dropped into an existing ceiling mount or set on a table and squared up without moving the projector. Throw ratio runs 1.09:1 to 1.77:1, covering images from about 30 to 300 inches, and dynamic contrast is rated 3,000,000:1.
Solid Shine laser illumination replaces the lamp entirely, rated at 20,000 hours in Normal mode and 24,000 hours in ECO, and 6-point screen correction squares the image on curved or corner surfaces. Connectivity includes two HDMI inputs, two computer (VGA) inputs, DIGITAL LINK over RJ-45 for running video, audio and control down a single CAT cable, plus network, RS-232 and USB. The white chassis weighs 6.5 kg (14.3 lb) and runs at 26 dB in ECO mode.
| Display | 3LCD, 0.64-inch panels |
|---|---|
| Resolution | WXGA (1,280 x 800), 4K signal input |
| Brightness | 5,200 lm (ISO) |
| Contrast Ratio | 3,000,000:1 (dynamic) |
| Light Source | Laser, 20,000 h (Normal) / 24,000 h (ECO) |
| Lens | 1.6x manual zoom, manual focus |
| Throw Ratio | 1.09:1 - 1.77:1 |
| Lens Shift | Horizontal +/-20%, vertical +44% |
| Image Size | 30 - 300 in |
| Terminals | HDMI x2, VGA x2, DIGITAL LINK (RJ-45), LAN, RS-232, USB, audio in/out |
| Speaker | 10 W monaural |
| Weight | 6.5 kg (14.3 lb) |
| Noise Level | 36 dB (Normal) / 26 dB (ECO) |
