MuxLab 500222 Passive Ceiling Speaker 8 Ohms/70V/100V, 40W
The 500222 pairs a 1-inch titanium dome tweeter with a 6.25-inch graphite-cone woofer for 40W of clean output, running 96Hz to 20kHz. It works as a straight 8-ohm speaker or on a 70V/100V distributed line with adjustable taps for level.
Adjustable taps let one amplifier zone feed ceiling speakers at different volumes without a per-speaker attenuator, which is the point of a 70V/100V system in the first place. It covers background paging and music in offices, retail, and hospitality ceilings.
| Signal | Tweeter: 1 in (25mm) titanium dome |
|---|---|
| Power Output | 40 Watts RMS |
| Compatibility | Woofer: 6.25 in (165mm) graphite cone, rubber surround |
| Dimensions | 4.34H x 4.65W in (11.02 x 11.81 cm) |
| Weight | 4.300 kg |
| Impedance | 8 ohm |
| Compliance | 70V/100V cascaded applications with adjustable taps |
| Frequency Range | 96 Hz - 20 kHz (+/- 3dB) |
