Crown CDi 2|300 DriveCore Amplifier
The CDi 2|300 puts 300 W behind each of its 2 channels and drives 70Vrms or 100Vrms distributed lines straight from the output, so a medium install skips the step-up transformer entirely. Crown aims the CDi DriveCore line at cinemas, houses of worship, bars, and meeting rooms, where the amplifier gets racked once and then has to be left alone.
Onboard DSP handles crossover, EQ, delay, and limiting, and the line ships pre-loaded with factory JBL speaker tunings so a common loudspeaker can be dialled in from the front panel rather than a laptop session. Analog inputs take it from a house mixer or paging system, and network control and monitoring are onboard for remote supervision.
| BLU link | No |
|---|---|
| Channels | 2 |
| Sensitivity (for full rated power at 8 ohms) | 0.7V RMS |
| Rated Power Output (per channel @ 4 ohms) | 300W |
| Analog Input Signal to Noise Ratio (ref. rated power, 100V, 20Hz - 20kHz) at 8 ohms) | > 104dB |
| THD (full rated power, 20 Hz - 20 kHz) | 0.35% |
| Dimensions (inches) (W x H x D) (depth not including 1.3 inch front panel protrusion) | 19 x 3.5 x 12.25 |
| Weight | 14.56 lbs (6.6 kg) |
