Crestron 1 Beyond IV-CAM-I12D-B Intelligent 4K Dual Camera Speaker Tracking Solution

The i12D is a single-bar speaker tracking solution: two 1/2.8 4K Sony CMOS sensors, a 12x optical PTZ block and a 110 degree reference camera, with the visual AI running on board. It handles speaker tracking, group framing, conversation mode and intelligent switching itself, which removes the separate tracking appliance a dual-camera setup would otherwise need. Up to 512 presets are configurable, and audio reference arrives on a balanced 3-pin terminal block so tracking can key off the room microphones.

Outputs are HDMI, USB and RTSP at up to 4K30, with 1080p and 720p modes down to 360p30 over USB. Networking is gigabit Ethernet with AES67 input, VISCA passthrough and VISCA over IP, PELCO-D, PELCO-P and UVC control. The USB-C host port carries video and control to a codec, and the camera is set up through Crestron 1 Beyond Camera Manager 2. Power comes from the PW-2420RU 24 VDC pack rather than PoE, and the matching i12D wall mount bracket is included.
