Biamp Desono MASK6C Surface-Mount Loudspeaker
The Biamp Desono MASK6C is a two-way, surface mount, indoor / outdoor loudspeaker built for business audio and installed sound systems. Drivers are LF 1 x 6.5 inch; HF 1 x 1 inch. The transducer complement is LF 1 x 6.5 inches (165 mm) coated paper cone; HF 1 x 1 inch (25 mm) soft dome. Its operating range is 65 Hz - 22 kHz.
Power handling is rated at 35V: 150W @ 8 ohms (600W peak). Biamp recommends 150W - 300W @ 8 ohms (35V - 49V) of amplifier power. Nominal impedance is Continuous Power Handling@ Nominal Impedance; 35V: 150W @ 8 ohms (600W peak). Audio: Audio connections made at the ClickMount bracket; lever-action input and output terminals accept up to 16 AWG conductors. Order it in 4 versions: MASK6C-BL, MASK6C-W, MASK6CT-BL, MASK6CT-W.
| Loudspeaker Type | Two-way, surface mount, indoor / outdoor loudspeaker |
|---|---|
| Transducers | LF 1 x 6.5 inches (165 mm) coated paper cone; HF 1 x 1 inch (25 mm) soft dome |
| Drivers | LF 1 x 6.5 inch; HF 1 x 1 inch |
| Operating Range | 65 Hz - 22 kHz |
| Sensitivity | (1W/1m) 89 dB |
| Power | 35V: 150W @ 8 ohms (600W peak) |
| Dimensions (H x W x D) | 12.9 inches (328 mm) x 7.8 inches (198 mm) x 7.5 inches (190 mm) |
| Impedance | Continuous Power Handling@ Nominal Impedance; 35V: 150W @ 8 ohms (600W peak) |
