Crestron CEN-SWPOE-26 26-Port PoE+ Network Switch

The CEN-SWPOE-26 is the lighting-network member of the family. Twenty-six 1000Base-T Gigabit ports, twenty-four of them PoE+ at up to 30 W each with a 300 W combined budget, plus four 1 Gigabit Base-X SFP ports, running on a 60 Gbps non-blocking fabric with Layer 2 and Layer 3 managed switching and LLDP.

The difference from the AV switches is where it goes: it mounts inside a Crestron lighting enclosure as readily as in a 19 in. rack, which is what keeps a floor's worth of PoE keypads and sensors on one switch near the panel instead of cabled back to the AV room. It is 1U, 17.32 by 10.11 in., 9.47 lb, draws 4.4 A at 100-240VAC, and consumes 401 W at full PoE, 35.8 W with none.

Ports	(2) 10/100/1000Base-T Gigabit Ethernet; (24) 10/100/1000Base-T Gigabit Ethernet with PoE+; (4) 1 Gigabit Base-X SFP
PoE	IEEE 802.3at Type 2 on 24 ports, up to 30 W per port, 300 W maximum combined
Network Standards	IEEE 802.3af, 802.3at
Switch Fabric	60 Gbps non-blocking
MAC Addresses	Up to 16K
Mounting	Lighting enclosure or 1U 19-inch rack with reversible rack ears
Main Power	4.4 Amps at 100-240 Volts AC, 50/60 Hz
Power Consumption	Max PoE 401 W; no PoE 35.8 W; standby 23.4 W
Dimensions	1.7 in. H x 17.32 in. W x 10.11 in. D (43.2 x 440 x 257 mm)
Weight	9.47 lb (4.3 kg)
