Crestron CEN-SWPOE-48 48-Port PoE+ Managed Switch

The CEN-SWPOE-48 is the floor switch: forty 1000Base-T Gigabit ports, every one PoE+ at up to 30 W with a 960 W total budget, plus eight 10 Gigabit Base-X SFP+ ports for uplinks and inter-switch fibre. A 240 Gbps non-blocking fabric carries a full complement of DM NVX encoders and decoders at once.

Selectable DM NVX and DM NAX profiles set the multicast configuration in a single step, with Layer 2 and Layer 3 managed switching, LLDP, a web interface and an advanced CLI alongside. It is 1U at 17.32 by 15.74 in. and 13.91 lb, draws 12 A at 100-240VAC, and consumes 1197 W at maximum PoE, 89.2 W with none. The TAA compliant variant is the same switch built to Trade Agreements Act sourcing requirements.

Ports	(40) 10/100/1000Base-T Gigabit Ethernet with PoE+; (8) 10 Gigabit Base-X SFP+
PoE	IEEE 802.3at Type 2 on all Ethernet ports, up to 30 W per port, 960 W total
Network Standards	IEEE 802.3af, 802.3at
Switch Fabric	240 Gbps non-blocking
MAC Addresses	Up to 16K
AV Profiles	Selectable DM NVX and DM NAX AV-over-IP profiles
Main Power	12 Amps at 100-240 Volts AC, 50/60 Hz
Power Consumption	Max PoE 1197 W; no PoE 89.2 W; standby 74.5 W
Dimensions	1.7 in. H x 17.32 in. W x 15.74 in. D (43.2 x 440 x 400 mm)
Weight	13.91 lb (6.31 kg)
