Crestron CEN-SWPOE-ULTRA-12 12-Port Ultra PoE Managed Switch

The CEN-SWPOE-ULTRA-12 is the twelve-port switch with the high-power PoE budget. Ten 1000Base-T Gigabit ports, eight of them PoE++ to IEEE 802.3bt Type 3 at up to 90 W each with a 720 W total budget, plus two 10 Gigabit Base-X SFP+ ports for the uplink, on a 60 Gbps non-blocking fabric.

That is the switch for a room where the endpoints draw real power: PoE ceiling speakers, DM NAX amplifiers, powered touch screens. Selectable DM NVX and DM NAX profiles set the multicast handling in one step. It is 1U at 17.32 by 10.11 in. and 8.44 lb, draws 10 A at 100-240VAC, and consumes 837.7 W at maximum PoE, 26.3 W with none.

Ports	(2) 10/100/1000Base-T Gigabit Ethernet; (8) 10/100/1000Base-T Gigabit Ethernet with PoE++; (2) 10 Gigabit Base-X SFP+
PoE	IEEE 802.3bt Type 3 on 8 ports, up to 90 W per port, 720 W total
Network Standards	IEEE 802.3af, 802.3at, 802.3bt
Switch Fabric	60 Gbps non-blocking
MAC Addresses	Up to 16K
AV Profiles	Selectable DM NVX and DM NAX AV-over-IP profiles
Main Power	10 Amps at 100-240 Volts AC, 50/60 Hz
Power Consumption	Max PoE 837.7 W; no PoE 26.3 W; standby 18 W
Dimensions	1.7 in. H x 17.32 in. W x 10.11 in. D (43.2 x 440 x 257 mm)
Weight	8.44 lb (3.83 kg)
