VigilLink VLPT-42MCSDH 4x2 Master Collaboration Switch with Dante and HDBaseT 3.0

The VLPT-42MCSDH is a 4x2 collaboration switch built around two full-function USB-C inputs and two HDMI inputs, mirrored to an HDMI output and an HDBaseT 3.0 output reaching 100 meters. Each USB-C input carries 4K video, 10Gbps USB 3.2 data, USB Ethernet, and 60W charging on the one cable a laptop already has.

Four USB 3.2 device ports serve shared conferencing peripherals, with automatic, priority, and independent USB and video switching so the camera and microphone follow the active presenter. Dante audio output and balanced audio de-embedding cover the sound path, and control runs over RS-232, GPIO, and relay with 802.1X secured networking.

HDR	All HDR formats, including HDR 10, HLG, HDR 10+ and Dolby Vision
Control Method	Front Panel Buttons, RS232, LAN (Telnet &Web UI)
Product Weight	1.45kg/3.20lbs
Power Supply	DC 20V, 10A
Input/Output Signal Type	Supports HDMI 2.0 standard, up to 4K@60Hz 4:4:4 8bit or 4K@60Hz 4:2:2 12bit. Supports HDCP 2.2/1.4
USB HOST IN 1 & 2	Supports USB 3.2 Gen 2x1 standard, up to 10Gbit/s
USB DEVICE	Maximum supports USB 3.2 Gen 2x1 standard, up to 10Gbit/s. 5V/1.5A output per port.s
Ethernet	1000M/100M adaptive network
