Whirlwind Concert Series Microphone Splitter Rack Panel

The Concert Series is Whirlwind's standing answer to the touring mic split: microphone inputs wired straight through to a Main Out multipin, and paralleled or transformer isolated to a Split Out multipin for the second console. Every input has a ground-lift switch on the Split Out, and return lines are hardwired to both multipins so monitor sends do not need their own run.

These are the rack panel versions, built on an EIA 19 inch panel with a back box enclosure. Concert 40 gives 32 female XLR inputs and 8 male XLR returns in 8U; Concert 58 gives 48 inputs and 10 returns in 10U; Concert 58NR gives 58 inputs and no returns in 12U. Transformer versions use Whirlwind TRSP-1F transformers. All are also available as a three-way split on request.
