DOD Boneshaker
Built with Black Arts Toneworks, the Boneshaker pairs a dirty boost with a 3-band semi-parametric EQ, so the pedal both drives the front end of an amp and decides exactly where that drive sits in the spectrum. Distortion sets the grit, Depth adds low-end growl, and Level trims the output; the Low, Mid and High bands each get their own boost/cut knob plus a frequency selector, which is what lets it push an already-overdriven channel forward in a mix or reshape a fuzz downstream of it.
It is true bypass with a blue status LED, takes a 1/4-inch instrument jack in and out, and runs from a 9V alkaline battery or an optional external supply. The all-metal chassis measures 4.68 x 2.63 x 2.25 inches and the pedal weighs 1.0 lb.
| Effect | Dirty boost with 3-band semi-parametric EQ |
|---|---|
| Controls | Distortion, Depth, Level, Low, Low Frequency, Mid, Mid Frequency, High, High Frequency |
| Bypass | True bypass, blue status LED |
| Connectors | 1 x 1/4" instrument input, 1 x 1/4" instrument output |
| Power | 9V alkaline battery or optional external power supply |
| Chassis | All metal |
| Dimensions | 4.68 x 2.63 x 2.25 in (11.88 x 6.68 x 5.71 cm) |
| Weight | 1.0 lb (0.453 kg) |
