Crestron CEN-SWPOE-12 12-Port PoE+ Managed Switch

The CEN-SWPOE-12 is the rack-mount entry to the line: ten 1000Base-T Gigabit ports, eight of which supply PoE+ up to a 125 W combined budget, plus two 1 Gigabit Base-X SFP ports. A 24 Gbps non-blocking fabric handles a room's worth of DM NVX endpoints and DM NAX audio without oversubscription.

It occupies 1U at 17.32 by 7.87 in. and 6.28 lb, with reversible rack ears so it can face either way in a shallow cabinet, or sit freestanding on a shelf. Full-PoE draw is 163.9 W, dropping to 17.3 W under full mesh traffic with no PoE and 8.5 W in standby. Selectable DM NVX and DM NAX profiles configure the multicast behaviour an AV-over-IP system needs in one step rather than port by port, and a streamlined web browser interface, an advanced CLI and LLDP cover the rest of the commissioning. Layer 2 and Layer 3 managed switching, MAC table up to 16K.
