Blackmagic ATEM Television Studio 4K8 Switcher
The ATEM Television Studio 4K8 is an all-in-one live production switcher that scales from a single operator up to a full broadcast crew. It has 8 12G-SDI inputs, each with a dedicated standards converter that accepts formats all the way up to UHD 4K60, plus 10 12G-SDI aux outputs for feeding external recorders and monitors. The creative toolset covers four ATEM Advanced Chroma Keyers, two downstream keyers, two DVEs, SuperSource and two media players, so a small team can build a polished multi-camera show.
A built-in hardware H.264/AAC encoder streams straight to platforms over RTMP, either through the four-port 10G Ethernet switch or a shared internet connection over USB-C, and a master recorder captures the program at the same time. Power is redundant, with AC mains plus a 12V XLR DC input for battery or backup supply, and it is sold two ways: with a 2TB SSD installed (BMD-SWATEMTVSTC/K4K8/2) or with no internal storage (BMD-SWATEMTVSTC/K4K8/0) for recording to your own external disk.
- Media Pool Still Image Capacity20
- Media Pool Clip Capacity2 x up to 2160p60.
- Media Player Clip Length in 720 HD (no storage)1600 frames.
- Media Player Clip Length in 1080 HD (no storage)800 frames.
- Media Player Clip Length in 2160 UHD (no storage)200 frames.
| Part Number | BMD-SWATEMTVSTC/K4K8/2 (2TB) or BMD-SWATEMTVSTC/K4K8/0 (no storage) |
|---|---|
| Video Inputs | 8 |
| SDI Video Outputs | 12 |
| SDI Rates | 1.5G, 3G, 6G, 12G |
| Video Outputs | 1 |
| Total Audio Inputs | 2 x balanced analog audio, 1 x BNC 32 Ch MADI digital audio, 2 x RCA stereo analog audio, 1 x 5 pin XLR Talkback. |
| Total Audio Outputs | 4 x 1/4 inch Jack analog audio, 1 x BNC 64 Ch MADI digital audio, up to 50 active, 1 x 5 pin XLR Talkback. |
| SDI Audio Inputs | 4 Ch embedded audio on all SDI inputs. |
| SDI Audio Outputs | 16 assignable channels. |
| Timecode Connections | 1 x BNC In, 1 x BNC Out. |
| Reference Input | 1 x BNC In, 1 x BNC Out. Tri-Sync or Black Burst. |
| Video Input Re-Sync | On all 8 inputs. |
| Frame Rate and Format Converters | On all 8 inputs. |
| SDI Aux Outputs | 10 |
| SDI Program Outputs | 1 |
| Webcam Output | 2 x USB-C supporting 720p or 1080p at PGM frame rate. |
| Total Multi Views | 1 x ; 1 x HDMI 2.0 |
| Remote | RJ12 supports RS-422 |
| Control Panel Connection | Ethernet. Direct connection between panel and chassis, or via network. |
| Internal Timecode Generator | Yes |
| Talkback | RJ45 for 3rd party talkback systems. |
| Tally Output | Added via ethernet connection to Blackmagic Design GPI and Tally Interface product. (Not included). |
| Ethernet | 4 x RJ45 with internet network switch. Supports 10/100/1000/10G BASE-T. |
| Computer Interface | 2 x USB-C supports USB 3.0 for external drive recording, webcam out, software control, software updates and switcher connection. |
| SD Video Standards | None |
| HD Video Input Standards | 720p50, 720p59.94, 720p60; 1080i50, 1080i59.94, 1080i60; 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 |
| Ultra HD Video Input Standards | 2160p23.98, 2160p24, 2160p25, 2160p29.97; 2160p30, 2160p50, 2160p59.94, 2160p60 |
| SDI Compliance | SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-1 and SMPTE 2082-10. |
| Video Sampling | |
| Color Precision | . |
| Color Space | Rec 709 |
| SDI Auto Switching | Automatically detects between 1.5G-SDI, level A or level B 3G-SDI, 6G-SDI and 12G-SDI. |
| Number of Mix Effects Rows | 1 |
| Direct Cross Points | 10 |
| Shifted Cross Points | 20 |
| Crosspoint Button Type | Tri-Color LED |
| Crosspoint Label | 6 rows 24 character LCD |
| Preview Transition | 1 |
| Source Select Bus | 1 |
| Dedicated Macro Buttons | 10 plus shift 10 |
| Transition Type Buttons | 5 |
| Transition Rate | Set via system LCD menu display |
| Key Buttons | 8 |
| AUX Buttons | 12 |
| Fader Bar | 1 |
| Record Buttons | 2 |
| Stream Buttons | 2 |
| DSK Transition Selectors | 6 |
| Fade to Black Buttons | 1 |
| System LCD Displays | 1 |
| Numeric Keypad | 1 |
| 3 Axis Joystick | 1 |
| Upstream Keyers | 4 |
| Downstream Keyers | 2 |
| Advanced Chroma Keyers | 4 |
| SuperSource | 1 |
| DVEs | 2 |
| Linear/Luma Keyers | 7 |
| Transition Keyer (Stinger/DVE) | 1 Stinger, 1 DVE. |
| Total Number of Layers | 8 |
| Pattern Generators | 7 |
| Color Generators | 2 |
| Control Panel | Integrated panel with full control of switching and settings. |
| Routable Windows | 16 |
| Windows Source Labels | Yes |
| Tally | Red for program and green for preview indication. |
| Talkback Support | Yes |
| Mix Minus Support | Yes |
| USB Audio Output (2TB) | Supports digital audio output over USB-C. Fully integrates with Fairlight Live. |
| Direct Streaming (no storage) | Supports direct live streaming using Real Time Messaging Protocol (RTMP) over ethernet or a shared internet connection over USB-C. |
| Direct Streaming (2TB) | Supports direct live streaming using Real Time Messaging Protocol (RTMP) and Secure Reliable Transport (SRT) over ethernet or a shared internet connection over USB-C. |
| Blackmagic Cloud Stream Router (2TB) | Supports streaming to Stream Router application in Blackmagic Cloud. |
| Direct Recording Video and Audio (no storage) | Direct recording to external media via USB-C expansion ports or optional internal M.2 flash memory. |
| Direct Recording Video and Audio (2TB) | Direct recording to the included internal M.2 flash memory or to external media via USB-C expansion ports. |
| Video Recording | HD programs recorded as a H.264 .mp4 file at the streaming quality setting and at the ATEM video HD standard with AAC audio. Ultra HD programs recorded as a H.265 HEVC file at the streaming quality setting and at the ATEM video Ultra HD standard with AAC audio. |
| Internal Memory (2TB) | 2TB M.2 NVMe installed. |
| Media Format | Supports media formatted ExFAT (Windows/Mac). APFS or HFS+ (Mac). |
| Multi View Monitoring | 1 x multi view via SDI and HDMI configurable to 16, 13, 10, 7 or 4 up views. Includes monitoring of Program, Preview, Inputs, Media Players, DSKs, SuperSource, Clean Feed with optional labels and audio meters. |
| Multi View Video Standard | HD or Ultra HD |
| Display Minimum Resolution | 1366 x 768 |
| Media Players | 2 |
| Channels | Fill and key for each media player. |
| Media Pool Still Image Capacity | 20 |
| Media Pool Still Image Format | PNG, TGA, BMP, GIF, JPEG and TIFF. |
| Media Pool Clip Capacity | 2 x up to 2160p60. |
| Media Player Clip Length in 720 HD (no storage) | 1600 frames. |
| Media Player Clip Length in 720 HD (2TB) | 720 frames. |
| Media Player Clip Length in 1080 HD (no storage) | 800 frames. |
| Media Player Clip Length in 1080 HD (2TB) | 360 frames. |
| Media Player Clip Length in 2160 UHD (no storage) | 200 frames. |
| Media Player Clip Length in 2160 UHD (2TB) | 90 frames. |
| Media Pool Video File Format | TGA sequence. |
| Media Pool Audio File Format | WAV, MP3 and AIFF. |
| Processing Delay | < 10 lines when genlocked and in the same format as the switcher. |
| Audio Mixer | 58 Channel mixer. Selectable On/Off/Audio-Follow-Video. Level and Peak metering. Master gain control. 6 band parametric EQ, Dynamics including Expander, Gate, Compressor and Limiter. |
| Camera Control | When used with most Blackmagic Design cameras, ATEM can control focus, iris and zoom of compatible lenses and camera settings including gain, white balance, tint, shutter, ND filter, color corrector, tally and record start/stop. |
| Down Conversion | 1 x multi view |
| Control Panel Included | ATEM Software Control panel included free for Mac and Windows. |
| Software Updates | Using USB or Ethernet connection directly connected to Mac or Windows computers. Includes ATEM Setup Utility |
| Configuration | Most switcher configurations are set in ATEM Software Control. To set an ATEM switcher IP address, use the ATEM Setup Utility with a direct USB connection to the switcher. |
| Operating Systems | Mac 14.0 Sonoma, Mac 15.0 Sequoia or later. Windows 10 and 11. |
| Power Supply | 1 x Internal 100 - 240 AC 50/60Hz with IEC C14 socket. 1 x 4 pin XLR 12V DC In for external power supply or battery use. |
| Power Usage | 120 W |
| Physical Installation | Desktop or in-desk mount. |
| Operating Temperature | 0° to 40° C (32° to 104° F) |
| Storage Temperature | -20° to 60° C (-4° to 140° F) |
| Relative Humidity | 0% to 90% non-condensing |
| Source | Full specifications on blackmagicdesign.com |

- ATEM Television Studio 4K8
- Welcome wallet with QR code for software download
