VigilLink VLML-SDH3X2 UHD+ 3x2 SDI and HDMI Matrix with PiP

The VLML-SDH3X2 is a 3x2 matrix with integrated scaling and multi-windowing, built to show several sources at once. It is aimed at monitoring endoscopes, X-ray systems, ultrasonic devices, and the da Vinci Surgical System side by side during a procedure or a diagnosis.

SDI and HDMI resolutions reach 4K@60Hz on both input and output, with LPCM audio to 7.1 channels at 192kHz and full HDCP 2.x compliance. SDI inputs run up to 60 meters. Switching is seamless, PiP, PoP, side-by-side, and auto modes are supported, window arrangements store as presets, and each window can carry a border in a selectable color.
