VigilLink VLMX-0808E 8x8 HDMI 2.0 Matrix Switcher with Downscaling

The VLMX-0808E distributes video up to 4K2K@60Hz 4:4:4 and multichannel digital audio from eight HDMI sources to eight HDMI displays. Each output carries an independent 4K-to-1080p downscaler for mixed display environments.

Audio de-embedding provides analog and coaxial outputs from every HDMI output port, and with ARC enabled display audio routes back to the coaxial outputs. Control is available from the front panel and the usual remote interfaces. HDR, HDR10, HDR10+, and Dolby Vision pass through, with LPCM 7.1, Dolby TrueHD, and DTS-HD Master Audio supported.

HDMI Compliance	HDMI 2.0b
HDCP Compliance	HDCP 2.2 and HDCP 1.4
Video Bandwidth	18Gbps
Video Resolution	Up to 4K2K@50/60Hz (4:4:4)
Input Ports	8xHDMI Type A [19-pin female] 1xIR EXT [3.5mm Stereo Mini-jack]
HDMI IN / OUT	16ft / 5M
Output Ports	8xHDMI Type A [19-pin female] 8xCoax Audio (RCA) 8xL/R Audio [3.5mm Stereo Mini-jack]
HDMI Audio Formats (Pass-through)	LPCM 2/5.1/7.1, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X
