VigilLink VLEX-HT2070R-TR HDBaseT 2.0 HDMI Extender with ARC, 70m

The VLEX-HT2070R-TR carries 18Gbps HDMI at 4K2K@60Hz RGB/YCbCr 4:4:4 across a single Cat5e/6 cable to 230 feet (70 meters), along with control and return-channel data. It is the version to specify when the far-end display needs to send its own audio back to the rack.

The extender converts HDMI to standard HDBaseT for the run and supports bidirectional IR pass-through for remote operation of either the source or the display. RS-232 control travels on the same cable, and the pair is HDMI 2.0b and HDCP 2.2 compliant.

HDMI Compliance	HDMI 2.0b
HDCP Compliance	HDCP 2.2
Video Bandwidth	18Gbps
Video Resolution	Up to 4K2K@60Hz RGB/YCbCr 4:4:4
Audio Formats	HDMI: LPCM 7.1CH, Dolby True HD, and DTS-HD Master Optical: Dolby 5.1, DTS 5.1, PCM 2.0
Color Space	RGB, YCbCr 4:4:4, YCbCr 4:2:2
Color Depth	8-bit, 10-bit, 12-bit (1080P) 8-bit (4K60) 8-bit, 10-bit, 12-bit (4K24/30)
HDR	HDR, HDR10, HDR10+, Dolby Vision, HLG
